非管理型 POE+ 工业交换机 8 x 10/100/1000 RJ45

SWITCH 2008GT-POE

7- POE+/ 1- Ethernet port unmanaged industrial Gigabit Ethernet switch

德国设计

职能

Flow Control, Storm Control, LLDP Filter, VLAN Passthru, Port Priority (p1-2), 802.1p/Tag QoS, EIP QoS (via TCP/UDP #), PROFINET QoS (via VLAN 0), GOOSE QoS (via Ether-type)

特点

Power over Ethernet (PoE+)
VLAN-支持
Profinet的最佳带宽利用
为EtherNet/IP提供最佳的带宽利用率

有问题吗？

Datasheet SWITCH 2008GT-POE 下载

订货号： SA-2008-GP-01-00

其他信息

The 7-port industrial POE+ Gigabit Ethernet switch of SALZ Automation, along with one standard Ethernet port, is an unmanaged industrial POE+ Gigabit Ethernet switch specifically designed to meet the demands of heavy industrial environments. Encased in rugged IP30-grade housing, this switch guarantees reliable and continuous operation, even in the most challenging conditions, making it a perfect networking solution for industrial applications. With Quality of Service (QoS), it supports Profinet applications, offering a cost-effective solution. The SWITCH 2008GT-POE is now equipped with 7 x POE+ 10/100/1000BASE-T ports and 1 x 10/100/1000BASE-T port, supporting both Gigabit and Fast Ethernet options with Auto MDI/MDIX and Auto-negotiation for enhanced connectivity flexibility. High-speed data transmission is complemented by the support of a 9K jumbo frame to boost throughput, and QoS on ports 1 to 7. Additionally, it supports PROFINET, GOOSE, and EtherNet/IP protocols to ensure the timely delivery of critical data. Features such as a redundant power supply with a wide-range input, a built-in relay alarm for immediate notification of power and port issues, DIN-Rail mounting, and more, continue to address the unique requirements of Industrial Ethernet networks.

IEEE标准

介面

开关功能

输入数据

机械数据

环境条件

尺寸

标准和法规

商业数据

IEEE标准返回顶部

IEEE 802.3	10Base-T
IEEE 802.3U	100Base-TX
IEEE 802.3AB	1000Base-T
IEEE 802.3X	Flow Control
IEEE 802.1P	Quality of Service(QoS)
IEEE 802.3AF	Power over Ethernet
IEEE 802.3AT	Power over Ethernet Plus
IEEE 802.3AZ	EEE

介面返回顶部

端口 (RJ45)	7 x 10/100/1000Base-T POE+ and 1 x 10/100/1000BASE-T RJ45 ports
拨码开关	Flow Control, STorm Control, EEE, LLDP Filter
LED 面板	PWR, PoE+, 1000, LNK/ACT

开关功能返回顶部

巨型帧大小	9 Kbytes
MAC 表大小	4K
L2转发速率	11.9 Mpps
吞吐量	14,880 pps to 10 Mbps ports; 148,800 pps to 100 Mbps ports; 1,488,000 pps to 1000 Mbps ports
PoE/PoE+	Scheduling, PD Alive Check, PoE Power On/OFF, Feeding Power Budget Control
每个端口的 PoE 功率	30 W

输入数据返回顶部

输入电压范围 DC	24 ... 57 V
输入电流	1 A
最大功耗	17 W
功耗 PoE 预算	120 W @ 24 VDC; 210 W @ 48 VDC

机械数据返回顶部

外壳	Metal case (IP30 protection)
符合 EN 60715的DIN安装导轨	TH35
重量	1,005 g

环境条件返回顶部

环境温度 (运行)	-10 °C ... 60 °C
环境温度 (存储/运输)	-40 °C ... 85 °C
工作湿度 (非冷凝)	5 ... 95 % RH
存储湿度 (非冷凝)	5 ... 95 % RH

尺寸返回顶部

宽度（毫米）	50 mm
深度（毫米）	120 mm
高度（毫米）	160 mm

标准和法规返回顶部

电磁干扰 (EMI)	FCC Part 15 Subpart B class A; EN 55022 class A; EN 55011:class A; EN 61000-6-4; CISPR32: class A; CISPR 11: class A; ICES-003
环境管理系统 (EMS)	EN 55035/UKCA; EN 61000-6-2; EN 61000-4-2 ( ESD ) : Level 3; EN 61000-4-3 ( RS ) : Level 3; EN 61000-4-4 ( Burst ) : Level 3; EN 61000-4-5 ( Surge ) : Level 3; EN 61000-4-6 (CS): Level 3; IEC61000-4-8(PFMF)
自由落体测试	IEC 60068-2-31
安全标准	UL61010-1/ UL 61010-2-210
RoHS	Yes

商业数据返回顶部

关税税号

85176200

7 x Gbit PoE+ 端口

7 x 10/100/1000 BASE-T RJ45 POE+端口

Power over Ethernet (PoE+)

With PoE (Power over Ethernet), PD (Powered Devices) are supplied with electrical energy. This energy is supplied via the Ethernet cable, which saves additional cables to the end device. PoE+ offers a maximum supply of 30 W at 50 - 57 V.
